ECG / EKG Testing
WhaleTeq ECG test solution is exclusively for manufacturers and certification laboratories. Our test solution verifies ECG devices with the most advanced assistant software, including performance tester SECG 5.0 AIO and SECG 4.0, ECG database player MECG 2.0, common mode rejection ratio tester CMRR 3.0+, medical database comparison software RDCA/CDCA and HFCN test fixture.
Moreover, WhaleTeq TRF Generator software is the ultimate test solution for compliance testing required by IEC 60601-2-25, IEC 60601-2-27, and IEC 60601-2-47 － simplifies all your efforts to conduct testing and generate TRF reports, and works with the SECG 5.0 AIO, the SECG 4.0, and the CMRR 3.0+.
The ECG test solution puts the completed testing and verification tool in your hands. It's compliant with regulatory required tests such as IEC 60601-2-25, IEC 60601-2-27, IEC 60601-2-47; AAMI/ANSI EC11, AAMI/ANSI EC13; China YY1079, YY1139, YY0782, and YY0885, providing the confidence and convenience for quality assurance.
| Medical Standard (1) | SECG 5.0 AIO (2) | SECG 4.0 | MECG 2.0 | CMRR 3.0+ | CDCA | RDCA | HFCN |
|---|---|---|---|---|---|---|---|
| IEC 60601-2-25 | O | O | O | O | O | O | |
| IEC 60601-2-27 | O | O | O | O | |||
| IEC 60601-2-47 | O | O | O | O | O | ||
| GB 9706.225-2021 | O | O | |||||
| GB 9706.227-2021 | O | O | |||||
| YY 9706.247-2021 | O | O | |||||
| YY0782-2010 | O | O | O | O | O | ||
| YY0885-2013 | O | O | O | O | O | ||
| YY1079-2008 | O | O | O | O | |||
| YY1139-2013 | O | O | O | ||||
| JJG 760-2003 | O | O | O | ||||
| JJG 1041-2008 | O | O | |||||
| JJG 1042-2008 | O | O | O |
Note:
(1) Please refer to the ''Supported Medical Standard Cross Reference Table'' for more information on supported test items.
(2) The SECG 5.0 AIO is compatible with various testing modules for SpO2 and PWTT testing, making it suitable not only for ECG performance verification but also for multiple vital signs performance testing in patient monitors.
Please visit the SECG 5.0 AIO product page for more information.
